Product Introduction:
The 800194923 is a fuel water separator assembly designed for use in XCMG construction machinery. It is a maintenance component that removes water and solid contaminants from diesel fuel to protect the engine fuel system.
1. Installation Location
This separator is installed in the diesel fuel supply line between the fuel tank and the engine. It is typically mounted on the chassis or engine frame, positioned for easy access during routine maintenance. The assembly dimensions are approximately 24×13×13 cm with a net weight of 1.65 kg.
2. Function
The separator removes free water and particulate contaminants from diesel fuel before they reach the high-pressure fuel injection system. It uses a filtration medium with oleophilic and hydrophobic properties to separate water molecules from fuel, preventing water-related corrosion and injector damage. Clean fuel delivery helps extend the lifespan of fuel system components and reduce maintenance requirements.
3. Maintenance and Service
This component is a serviceable assembly that requires periodic inspection and replacement. The separator should be checked regularly for accumulated water, and the filter element should be replaced according to the equipment manufacturer's recommended service intervals. If the assembly becomes clogged or damaged, replacement with an identical 800194923 unit is recommended. Always depressurize the fuel system before removal.
4. Important Notes
Verify the part number 800194923 matches the original component specification for the specific XCMG model before installation. Use only clean diesel fuel meeting manufacturer specifications to maximize separator service life.
