Product Introduction:
The 800195111 is a secondary (fine) fuel filter used in XCMG construction machinery diesel engines. It serves as a replacement part for the original equipment manufacturer's fuel filtration system . This filter is a paper-element type with typical dimensions around 124/128mm outer diameter and 234/248mm total height .
1. Installation Location
This filter is installed in the engine fuel supply line, typically downstream of the primary fuel filter/water separator. Its position in the system ensures it filters fuel after initial coarse separation, capturing finer contaminants before the fuel enters the high-pressure injection pump and injectors.
2. Function
The secondary fuel filter removes fine particles and contaminants from diesel fuel that may have passed through the primary filtration stage. Clean fuel is critical for protecting precision fuel system components such as injectors and high-pressure pumps from abrasive wear. Common OE cross-references for this filter include FS53075NN, FS20418, and FS20353 .
3. Maintenance and Service
This is a service item that requires periodic replacement according to the equipment manufacturer's maintenance schedule. The filter element is non-serviceable and must be replaced as a complete unit. If fuel flow restriction occurs or the filter becomes clogged, replacement with an identical 800195111 unit is recommended. Always depressurize the fuel system before removal.
4. Important Notes
Always verify the part number 800195111 matches the original component specification for the specific machine model. The filter is compatible with various XCMG equipment including loaders and other construction machinery
